GENERAL
• Audio/video playback with USB stick up to 32 GB
• Front 3.5 mm audio/video input
• Front USB 2.0 input with 1.0 A charging rate
• Video input for rear view camera
(normal and opposite hand)
• 5 line audio outputs: 2x front, 2x rear and
subwoofer (2V RMS / 500-ohms)
• Video output for TFT monitor connection
• Steering Wheel Control (SWC), connection via optionally
available adapter (compatible with Dietz UNICO DUAL
PLUS (art.-no. 66040) with cable (art.-no. 66405), PAC
(Pacific Accessory Corporation) SWI-PS with Metra
ASWC interface profile)
• Programmable 3-Band tone control with 6 preset and 1
user-defined equalizer curves (adjustable bass, midrange
and treble with 4 different mid frequencies and
4 different Q factors each)
• Sub X-over frequencies 80 / 120 / 160 Hz
• Programmable volume control for all audio sources
• Touchscreen calibration mode
• Power supply: 11 to 16 VDC, negative ground
• Power antenna (blue): 500 mA max, overcurrent
protection
• Operating temperature: -20°C to 65°C
• Fuse: 15A mini ATO
• DIN chassis dimensions: 178 x 178 x 50 mm
(7“ x 7“ x 2“)
• Weight: 2.15 kg net (incl. cable adapter)
• Multi language OSD (German, English, French)
• Made for iPod / made for iPhone
• Automatic switch-on of rear view camera mode
(normal & opposite hand)
DVD/CD Player
• Compatible disc media: DVD +/- R/ +/- RW
(single and dual layer) and CD-R/-RW
• Compatible media formats: CD-DA, MP3, WMA,
VCD, SVCD, Xvid, AVI, MPEG 1/2
• Signal to noise ratio: >95 dBA
• Dynamic range: >95 dB
• Frequency response: 20 Hz to 20 kHz, -3 dB
• Channel separation: > 60 dB at 1 kHz
• D/A converter: high performance 24-bit / 192 kHz
sample rate, multi-bit sigma-delta modulator
• Screen fomats: cinema, normal and off (standby)
CD / MP3 / WMA
• CD text compatible
• Display of album picture (ID3-tag compatible)
• Directory search (MP3 / WMA only)
• Playback of self-made CDs/ DVD+R/RWs with up
to 2000 MP3 and WMA files
Video
• Format: PAL / NTSC (auto-detection)
• Output: 1 Vp-p (75-ohm)
• Input: 1 Vp-p (75-ohm)
Video
• Format: PAL / NTSC (auto-detection)
• Output: 1 Vp-p (75-ohm)
• Input: 1 Vp-p (75-ohm)
FM Tuner
• RDS (Radio Data System): AF (Alternative Frequencies),
CT (Clock Time), EON (Enhanced Other Networks), PS
(Programme Service), PTY (Programme Type), RT (Radio
Text), TA (Traffic Announcements)
• Tuning range: 87.5 MHz – 107.9 MHz
• 18 station presets
• Auto stereo/mono
• Local/distance
• Mono sensitivity (-30 dB): 9 dBf
• Quieting sensitivity (-50 dB): 15 dBf
• Alternate channel selectivity: 70 dB
• Signal to noise ratio at 1 kHz: 58 dB
• Frequency response: 30 Hz – 15 kHz, -3 dB
